High-performance EVE 59Ah & CATL 93Ah cells are perfect drop-in upgrade replacements for LEV50 lithium batteries. Fully electrically compatible, they realize higher energy density, longer cycle lifespan and longer driving mileage, with easy installation and stable operation for classic electric vehicles.
LEV50 Battery Replacement Solution with CATL 93Ah or EVE 59Ah NMC Cell
Advanced Upgrade Solution for Mitsubishi i-MiEV / Peugeot iOn / Citroën C-Zero
1. Project Background
The Mitsubishi i-MiEV, Peugeot iOn, and Citroën C-Zero are among the earliest mass-produced electric vehicles in the global EV market. After years of operation, most original LEV50 battery modules are experiencing significant capacity loss, shortened driving range, reduced charging efficiency, and aging-related performance degradation.
As replacement OEM battery modules become increasingly limited and expensive, vehicle owners require a practical, high-performance, and cost-efficient upgrade solution. In response to this market demand, NOGI developed a modern LEV50 battery replacement system utilizing advanced CATL 93Ah and EVE 59Ah lithium cells.
2. Development Philosophy & Solution Origin
The core idea behind this project is to preserve the original vehicle platform while dramatically improving battery performance using newer-generation lithium technology.
- Restore and extend EV driving range.
- Increase battery energy density and cycle life.
- Maintain compatibility with original vehicle systems.
- Reduce replacement costs compared to OEM solutions.
- Provide sustainable long-term support for aging EV platforms.
Modern lithium-ion technology has evolved significantly compared to early-generation LEV50 cells. CATL and EVE cells offer improved energy density, voltage stability, safety performance, and service life. By integrating these cells into the original battery structure, NOGI created a balanced upgrade solution that combines modern battery performance with OEM-style integration.
3. Technical Upgrade Structure
| Category |
Parameter |
GS Yuasa LEV50
(Original Factory) |
EVE 59Ah |
CATL 93Ah |
| Basic Information |
Cell Chemistry |
NMC Ternary Lithium-Ion |
NMC Ternary Lithium-Ion |
NMC Ternary Lithium-Ion |
| Core Electrical Parameters |
Nominal Voltage (Per Cell) |
3.7V |
3.7V |
3.7V |
| Nominal Capacity |
50Ah |
59Ah |
93Ah |
| Operating Voltage Range |
2.75~4.2V |
2.75~4.2V |
2.75~4.2V |
| Energy Per Cell |
185Wh |
218.3Wh |
344.1Wh |
| DC Internal Resistance |
≈0.8mΩ |
≤0.6mΩ |
≤0.55mΩ |
| Cycle Life (25°C Standard) |
≥85% Capacity Retention After 1000 Cycles |
≥80% Capacity Retention After 2000 Cycles |
≥80% Capacity Retention After 2500 Cycles |
| Continuous Discharge Rate |
1C |
1.5C |
2C |
| Fast Charging Capability |
80% SOC in 30 Mins @ 25°C |
80% SOC in 25 Mins @ 25°C |
80% SOC in 20 Mins @ 25°C |
| Dimensional & Weight Specifications |
Cell Dimensions (H × L × T, mm) |
98 × 171 × 44 |
99 × 149 × 27 |
85 × 172 × 85 |
| Net Weight Per Cell |
≈1.7kg |
≈0.88kg |
≈1.43kg |
| Total Net Weight (88-Cell Vehicle Pack) |
≈149.6kg |
≈77.4kg |
≈125.8kg |
| Installation & Compatibility Metrics |
Dimensional Fit with Original LEV50 |
100% OEM Native Fit |
Near-Identical Height, Minor Length/Thickness Difference |
Significant Height/Thickness Difference, No Native Fit |
| Installation Difficulty |
★☆☆☆☆ Zero Difficulty |
★★☆☆☆ Low Difficulty |
★★★☆☆ Mid Difficulty |
| Modification Requirements for Original Enclosure |
No Modification Required, Direct Drop-In Installation |
No Enclosure/Lid Modification, Only Custom Bracket & Busbar Rerouting |
Full Battery Frame Cutting/Redesign, Cell Layout & Thermal Structure Reconfiguration |
4. Installation Process
1).Remove original LEV50 battery modules from the vehicle battery pack.
2).Install upgraded CATL 93Ah or EVE 59Ah cells using custom-designed brackets.
3).Connect busbars, balancing wires, and OEM communication interfaces.
4).Perform voltage balancing, BMS communication verification, and safety testing.
5).Reassemble battery pack and complete final road-performance validation.
5. Main Advantages of the Upgrade
- Extended Driving Range: CATL 93Ah configuration can significantly increase vehicle range up to approximately 300km.
- Higher Capacity: Provides more usable energy and improved power delivery.
- OEM-Compatible Integration: Supports original BMS communication and vehicle architecture.
- Enhanced Safety: Modern lithium cells offer improved thermal stability and reliability.
- Longer Cycle Life: Modern cell chemistry supports extended operational lifespan.
6. Market Outlook & Industry Potential
The global electric vehicle aftermarket is entering a major expansion phase as first-generation EVs begin requiring battery refurbishment and replacement solutions. Vehicles such as the Mitsubishi i-MiEV, Peugeot iOn, and Citroën C-Zero remain widely used in Europe, Japan, Australia, and emerging EV markets.
NOGI’s LEV50 replacement solution provides EV owners and refurbishment companies with a practical pathway to restore vehicle usability while significantly improving performance compared to aging OEM systems.
As demand for EV refurbishment continues growing, battery upgrade systems are expected to become an important sector within the global sustainable mobility industry. NOGI aims to continue expanding its product portfolio to support more EV platforms and future-generation replacement technologies.
7. Conclusion
The NOGI LEV50 Battery Replacement Solution represents a professional, scalable, and future-oriented EV upgrade system. By integrating advanced CATL and EVE lithium cells into the original vehicle platform, the solution delivers improved range, enhanced safety, stable performance, and long-term sustainability for electric vehicle users worldwide.
